Brass PPR & CPVC Fittings

Home Products
  • Brass Turned Components
  • Copper Metal Turned Components
  • Aluminium Components
  • Stainless Steel Components
  • Mild Steel Components
  • Sheet Metal Components
  • Earthing & Grounding Accessories
  • Brass Electrical Components
  • Brass Plumbing Fittings
  • Brass Sanitary Fittings
  • Brass PPR & CPVC Fittings
  • Brass Lamp Parts
  • Brass & MS Fasteners
  • Brass Automotive Components

Do you need any help?

+91 94267 87636

info@dharametal.com

Inquire Now

Description

We are manufacturing wide range of brass PPR/CPVC Fittings in different size, material, thread and type and exporting it to various countries. Our comprehensive range of Brass PPR/CPVC Fittings include male ppr fitting, female ppr fitting, male cpvc fitting, female cpvc fitting and more. These Brass PPR and CPVC fitting manufactured from high grade brass alloys and sophisticated techniques. All our brass PPR and CPVC fitting are adhering to DIN, JIS and other international norms and standards to fulfill the varied need of customer. We are capable to offer wide range of knurling including Diamond Knurling, Straight Knurling, Unidirectional Knurling or as per customer specification. Inner diameter (I/D) after threads with very close tolerance to prevent unnecessary flush to inter into the inserts. Our finest quality brass PPR/CPVC fitting are suitable for most of the applicable PPR Pipes, gas cylinders, electrical equipments and pipe line assembling.

Features : » Threads as per International Go & Not Go Standards.
» Deep Groove for maximum Pull Out Resistance.
» Inner Diameter (I/D) after Threads with very close tolerance to prevent unnecessary flush to enter into the brass inserts.
Knurling Available : » Diamond, Straight, Unidirectional, both blind and through inserts are available.
Material : » Free Cutting Brass IS 319 ( I ) / BS 249 / CZ121Pb3
» Free Cutting Brass IS 319 ( II ) / CZ124
» Free Cutting Brass IS 319 ( III ) / BS 249
» High Grade Free Cutting Brass
» Any Special Brass Material Composition as per customer requirements.
Threads : ISO metric, MM, PG, BSW, BSP, BSB, BSF, BA, NPT, NPTF, UNC, UNF, UNEF etc, Any threads as per customer's design
Length / Size : » 3/8”, 1/2”, 3/4”, 1”, 1.1/4”, 1.1/2”, 2”, 1.1/2”, 3”, 4”, 5” - As per Go Not Go Gauges & Deep Groove for maximum Pull Out Resistance
Finish And Coating : Natural, Nickel Plated, Tin Plated or any coating as per customer specification
